I let Gestinux create database from scratch but
during the creation of Queries table (in unit UnitDataModule, procedure DbAfterConnect, statement TableQueries.Check)

I get this error
Impossibile connettersi al server 127.0.0.1 con il nome utente nomorelogic (Unsupported field type for TableQueriesSqlCode Type=15)

I think this is due to this code : as you can see, "case aField.DataType of" doesn’t handle ftBlob case (field type of field SqlCode) and the result is the execution of the raise statement with the message above

//----------------------------------------------------------
// Returns the Sql keywords corresponding to a DataType
//----------------------------------------------------------
function TGTable.FieldTypeToSql(const aField: TField;
  const aProtocol: TDBMSType): string;

begin
  case aField.DataType of
    ftString: Result := 'VARCHAR(' + IntToStr(aField.Size) + ')';
    ftFixedChar: Result := 'CHAR(' + IntToStr(aField.Size) + ')';
    ftBoolean: if aProtocol in [Dbms_mysql, dbms_Oracle] then
        Result := 'TINYINT'
      else
        Result := 'BOOLEAN';
    ftAutoInc: if aProtocol = Dbms_pgsql then
        Result := 'SERIAL'
      else
        Result := 'INTEGER AUTO_INCREMENT';
    ftSmallint: Result := 'SMALLINT';
    ftInteger: Result := 'INTEGER';
    ftLargeint: Result := 'BIGINT';
    ftDateTime: if aProtocol = Dbms_pgsql then
        Result := 'TIMESTAMP'
      else
        Result := 'DATETIME';
    ftDate: Result := 'DATE';
    ftMemo: if aProtocol = Dbms_pgsql then
        Result := 'TEXT'
      else
        Result := 'LONGTEXT';
    else
      raise Exception.Create('Unsupported field type for ' + aField.Name +
        ' Type=' + IntToStr(Ord(aField.DataType)));
  end;
end;

best regards
nomorelogic

I think I’ve found something but still confused too.

Starting from the begin, my environment is :
mysql (innodb_version) 5.6.28
zeoslib 7.1.4

Different from yours but trouble I think is in FPC, cause I use Lazarus trunk wich uses FPC 3 instead of Lazarus 1.2.6 wich uses fpc 2.6.4.
In .../fpc/packages/fcl-db/src/base/db.pas there no changes : order is not changed, ftBlob = 15 in both cases

db.pas in fpc 2.6.4

  TFieldType = (ftUnknown, ftString, ftSmallint, ftInteger, ftWord,
    ftBoolean, ftFloat, ftCurrency, ftBCD, ftDate,  ftTime, ftDateTime,
    ftBytes, ftVarBytes, ftAutoInc, ftBlob, ftMemo, ftGraphic, ftFmtMemo,
    ftParadoxOle, ftDBaseOle, ftTypedBinary, ftCursor, ftFixedChar,
    ftWideString, ftLargeint, ftADT, ftArray, ftReference,
    ftDataSet, ftOraBlob, ftOraClob, ftVariant, ftInterface,
    ftIDispatch, ftGuid, ftTimeStamp, ftFMTBcd, ftFixedWideChar, ftWideMemo);

db.pas in fpc 3.0

  TFieldType = (ftUnknown, ftString, ftSmallint, ftInteger, ftWord,
    ftBoolean, ftFloat, ftCurrency, ftBCD, ftDate,  ftTime, ftDateTime,
    ftBytes, ftVarBytes, ftAutoInc, ftBlob, ftMemo, ftGraphic, ftFmtMemo,
    ftParadoxOle, ftDBaseOle, ftTypedBinary, ftCursor, ftFixedChar,
    ftWideString, ftLargeint, ftADT, ftArray, ftReference,
    ftDataSet, ftOraBlob, ftOraClob, ftVariant, ftInterface,
    ftIDispatch, ftGuid, ftTimeStamp, ftFMTBcd, ftFixedWideChar, ftWideMemo);

there’s something new in fpc 3, but this shoulnd’t break

{ TBlobField }
  TBlobStreamMode = (bmRead, bmWrite, bmReadWrite);
  // This type is needed for compatibility. While it should contain only blob
  // types, it actually does not.
  // Instead of this, please use ftBlobTypes
  TBlobType = ftBlob..ftWideMemo deprecated 'Warning: Does not contain BLOB types. Please use ftBlobTypes.';

  TBlobField = class(TField)

strange to me is that in unitdatamodule.lfm, SqlCode is defined as ftBlob and not as ftMemo !
I thought about RTTI troubles and I checked in sourceforce, code is following : BlobType = ftBlob.
So, I can’t figure out why I get thi error while you don’t.

    object TableQueriesSqlCode: TMemoField
      DisplayWidth = 10
      FieldKind = fkData
      FieldName = 'SqlCode'
      Index = 3
      LookupCache = False
      ProviderFlags = [pfInUpdate, pfInWhere]
      ReadOnly = False
      Required = True
      BlobType = ftBlob
      Transliterate = False
    end

Anyway I fixed that way, it works, but I have not figured out why 🙂
how is your lfm ?

    ftMemo {$IFDEF VER3_0}, ftBlob{$ENDIF}: if aProtocol = Dbms_pgsql then
        Result := 'TEXT'
      else
        Result := 'LONGTEXT';

tintinux
...
You proposed fix make MySQL field of type TEXT when BlobType is ftBlob.
I don’t know if it works. Did you tried storing and retrieving data ?
If it works, I don’t find it very consistant.
I would suggest to return BLOB when BlobType is ftBlob, but we have to check if the upgrade from 1.2 to trunk works fine, in recent(s) versions of MySql and PostGreSQL.
IMHO, my solution is simpler and have less unknown consequences.
What do you think ?

My fix was an attempt to bypass this bug to see if database generation process came to an end.
Now that we understand we need a real fix.

tintinux
My solution is to correct also the type of this field to ftMemo, and in any other place where ftBlob is used : it should work on your environment without other changes.

Store images as text is a nice idea.
About upgrading, on RDBMS side, fields have already been generated with the right DDL both in MySql and Postgres.
What we need is that the trunk continues to do things in the same way.

You’re right : Replace ftBlob with ftMemo everywhere in .flm I think is the best fix (and we have ftBlob type free to use natively the future).

best regards
nomorelogic

Hi

Storing images as texts is not a solution to "this problem", it is the opposite. The problem submitted in the thread was caused by wrong datatypes for some MySql fields, when storing images as text. This has been solved for 3 years. It is better to avoid reopening so old threads...

The choice to store images as texts in Gestinux allows a backup of the database containing only text, independent of the DBMS used, and that we can edit, save and exchange with tools working on texts.

As far as I know it is working fine and no important drawback was reported. It increases the size of the database storage, but this don’t look like an issue.

Best regards
